Electric Termil Greenheiss Five ERP 140L Vertical
Large capacity thermaciumulator with 140 liters and 2500W power for numerous families. Double Vitrified at 840 ° C according to DIN 4753-3, manufactured in S235JR structural steel with maximum strength and durability.
- â Capacity: 140 liters
- â Power: 2,500 W
- â Preparation Time: 2h 17min
- â Dimensions: Ă530 x 1090 mm
- â Energy classification: c
- â Production: 61,43 l / h
ÂżAny doubt about the product?
Talk to us and consult us. We will solve all your doubts
Electric Termo Greenheiss Five ERP 140 liters Vitrifier Vertical
Referencia: 2200035002
âŹ496.83
Tax included
î IMMEDIATE DELIVERY!
For deliveries in Europe, consult delivery time
EnvĂo GRATIS en España (PenĂnsula) a partir de 300⏠+ info
Email has been sent successfully.
Calcular Gastos de EnvĂo
đĄïž Pago Seguro â
GarantĂa Oficial
Electric Termil Greenheiss Five ERP 140L Vertical
Large capacity thermaciumulator with 140 liters and 2500W power for numerous families. Double Vitrified at 840 ° C according to DIN 4753-3, manufactured in S235JR structural steel with maximum strength and durability.
- â Capacity: 140 liters
- â Power: 2,500 W
- â Preparation Time: 2h 17min
- â Dimensions: Ă530 x 1090 mm
- â Energy classification: c
- â Production: 61,43 l / h
Security policy
Delivery policy
Refund policy
Electric Termil Greenheiss Five ERP 140L Vertical - Maximum capacity with superior power
The Greenheiss Five is ERP 140L Vertical It represents the maximum capacity for large families, light commercial facilities or homes with high demand for hot water health. Built Structural steel not alloy S235JR according to in 10025-2It provides exceptional structural resistance to support large volumes of water.
Its most outstanding feature is the 2.500W electrical resistance, significantly higher than standard models, which allows a faster and more efficient heating of 140 liters in approximately 2 hours and 17 minutes. The Double vitrified in oven at 840 ° C according to DIN 4753-3 standard It guarantees superior anticorrosion protection and purity of stored water.
With a Continuous production of 61.43 l / h (Facing 36.86 l / h of minor models), this thermoacumulator can satisfy multiple points of simultaneous consumption without reduction of temperature. The magnesium anode It provides additional galvanic protection, ensuring water free of metal contamination throughout the lifespan.
The Insulation of rigid polyurethane injected 20mm thickness with 42 kg / m³ density and conductivity λ = 0.022 W / mk minimizes thermal losses even in this great volume. Your Diameter of 530mm It provides optimal surface / volume ratio for maximum thermal efficiency.
With Energy Classification C and operation regime up to 8 bar and 75 ° C, offers professional benefits supported by 5 year warranty. The electrostatically varnished steel sheet finish ensures aesthetic durability and external corrosion resistance in any environment.
Technical specifications
| Feature | Value |
|---|---|
| Nominal / real capacity | 140-liter |
| Resistance power | 2,500 W |
| Preparation DHW (ÎT 35 ° C) | 2h 17min |
| Production DHW (ÎT 35 ° C) | 61.43 l / h |
| Dimensions (Ă x height) | Ă530 x 1090 mm |
| Empty weight | 42.5 kg |
| Maximum pressure | 8.0 bar |
| Maximum temperature | + 75 ° C. |
| Thickness isolation | 20 mm |
| Static losses | 69 W |
| Thermal dispersion | 1,66 kWh / day |
| Coefficient losses (UA) | 1.73 W / K |
| Energy classification | C. |
| Load profile | Meters |
| Main advantage | High power 2500W + great capacity |
| Code | 2200035002 |
2200035002
Data sheet
- Brand
- GreenHeiss
- Installation
- Vertical
- Consumption
- M
- Power (W)
- 2.000
- Volume (L)
- 140
- ERP class
- C
- High (mm)
- 1.090
- Width (mm)
- 530
- Deep (mm)
- 550
- Weight (kg)
- 43
