Circulating pump Nass CNV 25-10-180 low consumption
- Maximum flow rate: 86.6 litres/minute
- Maximum lift height 10 meters
- Connection dimensions 180 mm
- Includes 1 1/2" - 1"
- Frequency converter control
- PWM signal regulation mode, by internal control logic
- Maximum working pressure: 10 bar
- Nominal voltage: 1x230 V
- Liquid temperature: +2 °C to +110 °C
- Environment temperature: Maximum +40oC
¿Any doubt about the product?
Talk to us and consult us. We will solve all your doubts
Heating circulating pump Nass CNV 25/10 1x230V, PN10, 180mm, pipe connection 1"
Referencia: 0150000041
€277.60
Tax included
We are currently out of stock.
Ask us about availability!!
Envío GRATIS en España (Península) a partir de 300€ + info
Email has been sent successfully.
Calcular Gastos de Envío
🛡️ Pago Seguro ✅ Garantía Oficial
Circulating pump Nass CNV 25-10-180 low consumption
- Maximum flow rate: 86.6 litres/minute
- Maximum lift height 10 meters
- Connection dimensions 180 mm
- Includes 1 1/2" - 1"
- Frequency converter control
- PWM signal regulation mode, by internal control logic
- Maximum working pressure: 10 bar
- Nominal voltage: 1x230 V
- Liquid temperature: +2 °C to +110 °C
- Environment temperature: Maximum +40oC
Security policy
Delivery policy
Refund policy
CNV Circulator CNV Circulator with Frequency Variator CNV 25-10/180 low consumption
Circulating pump with energy efficiency type “A”. It meets the European Energy Efficiency Directive. Check Specially recommended for use in individual housing heating systems, substitutions, alterations and heating circuits in radiant floor installations.
Characteristics of the pumped liquid:
· Clean
· Free of solids and mineral oils
· Chemically neutral
- Liquid temperature: +2oC ~ +110oC.
- Environment temperature: up to 40oC.
- Maximum system pressure: 10 bar.
- Permanent magnet engine.
- Frequency converter control.
- Tension 230V. monophasic 50 Hz.
- Class F isolation.
- IP44 protection.
- Power cable with shuko plug.
- PH: 6.5 to 8.5.
0150000041
New
No customer reviews for the moment.
