Haier AP140S2SK1FA (H)
Column YR-HRS01 Three-phase Inverter
Haier AP140S2SK1FA (H) - Air conditioning Column YR-HRS01 three-phase with 13.4 kW of cold-fat power and 15.0 kW heat. Energy Efficiency A + cold and A ++ in heat with double rotary rotary and ecological R-32 refrigerant inverter. Three-phase feeding 380-415V Ideal for industrial installations. Advanced design with 3D air flow, horizontal and vertical grid movement, integrated UVC sterilization. Includes INTERIOR UNITS AP140SSK1FA (H) + outer 1U140S2SN1FB, integrated Wi-Fi control and automatic restart. Air flow Up to 1,850 m³ / h with silent operation from 46 dB (a). Perfect for commercial and industrial facilities of 130-160 m² that require three-phase air conditioning with UVC air purification.
⚡ Three-phase feeding 380-415V • UVC sterilization • Integrated Wi-Fi
¿Any doubt about the product?
Talk to us and consult us. We will solve all your doubts
Column Haier Health-Connect 140 trif. Air conditioning
Referencia: HAICOLUMCONNECT140T
€2,230.88
Tax included
We are currently out of stock.
Ask us about availability!!
Envío GRATIS en España (Península) a partir de 300€ + info
Email has been sent successfully.
Calcular Gastos de Envío
🛡️ Pago Seguro ✅ Garantía Oficial
Haier AP140S2SK1FA (H)
Column YR-HRS01 Three-phase Inverter
Haier AP140S2SK1FA (H) - Air conditioning Column YR-HRS01 three-phase with 13.4 kW of cold-fat power and 15.0 kW heat. Energy Efficiency A + cold and A ++ in heat with double rotary rotary and ecological R-32 refrigerant inverter. Three-phase feeding 380-415V Ideal for industrial installations. Advanced design with 3D air flow, horizontal and vertical grid movement, integrated UVC sterilization. Includes INTERIOR UNITS AP140SSK1FA (H) + outer 1U140S2SN1FB, integrated Wi-Fi control and automatic restart. Air flow Up to 1,850 m³ / h with silent operation from 46 dB (a). Perfect for commercial and industrial facilities of 130-160 m² that require three-phase air conditioning with UVC air purification.
⚡ Three-phase feeding 380-415V • UVC sterilization • Integrated Wi-Fi
Security policy
Delivery policy
Refund policy
Haier AP140S2SK1FA (H)
Column YR-HRS01 Three-phase Inverter
⚡ Three-phase system 380-415V • UVC sterilization • Wi-Fi integrated
Components of the three-phase system
| Indoor Unit: | Ap140s2sk1fa (pm) |
| Outdoor Unit: | 1u140s2sn1fb |
| Power: | 380-415V (3 phases) |
| Refrigerant Gas: | R-32 ecological |
| Compressor: | Double rotary inverter |
UVC technology and three-phase 3D
Advanced three-phase system that combines UVC sterilization to remove viruses and air bacteria, 3D airflow with horizontal and vertical grid movement, and integrated Wi-Fi control. Three-phase feeding guarantees greater electric stability, lower energy consumption and softer start, ideal for high demand industrial and commercial installations.
UVC sterilization
Eliminates viruses, bacteria and pathogens
Eliminates viruses, bacteria and pathogens
3D airflow
Uniform distribution
Uniform distribution
Wi-Fi control
Remote management complete
Remote management complete
Automatic mode
Smart operation
Smart operation
Dimensions and weight
| Interior: | 600 x 350 x 1.850 mm |
| Interior weight: | 50.0 kg |
| Exterior: | 950 x 370 x 965 mm |
| Exterior weight: | 85.0 kg |
Three-phase features
| Air flow: | 1,850 m³ / h (max.) |
| Interior sound level: | 46-52 dB (A) |
| Exterior sound level: | 58 dB (A) |
| Operating Range: | -20 ° C A + 46 ° C / -20 ° C A + 24 ° C |
Advantages of the three-phase system
Minor
Three-phase superior efficiency
Three-phase superior efficiency
Greater stability
Balanced distribution
Balanced distribution
Soft boot
Smaller peak
Smaller peak
Industrial installation
For large facilities
For large facilities
Recommended Industrial Applications
Ideal for three-phase facilities 130-160 m² that require high quality air with UVC sterilization and intelligent control.
Hospitals
Laboratories
Corporate offices
Shopping centers
Industrial facilities
Data centers
px 0; Font-Size: 18px; Border-Bottom: 2PX SOLID # 0066CC; Padding-Bottom: 8px; "> Three-phase general description
The Haier AP140S2SK1FA (H) is an air conditioner of three-phase column of the YR-HRS01 series with 13.4 kW of refrigeration power and 15.0 KW of heat power. It incorporates double three-phase rotary reverse technology with ecological R-32 efficiency compressor. Its three-phase feeding 380-415V is designed for industrial and commercial installations, combining UVC sterilization, integrated Wi-Fi control and 3D airflow for spaces 130-160 m² that require maximum air quality.
Power and three-phase efficiency
| Refrigeration capacity: | 13.4 kW (45,700 BTU / H) |
| Capacity Heating: | 15.0 kW (51,200 BTU / H) |
| Cold efficiency: | A + (Seer 5,66) |
| Efficiency Heat: | A ++ (Scop 4,80) |
| EER / COP: | 2,48 / 2.76 |
HAICOLUMCONNECT140T
Data sheet
- Brand
- Haier
- Indoor Unit
- AP140S2SK1FA(H)
- Outdoor Unit
- 1U140S2SN1FB
- I send
- Mando Infrarrojos
- Color
- Blanco
- Refrigerant Gas
- R32
- Electrical supply
- Trifásica
- Recommended area (M2)
- Estancia de 110 a 120 m2
- Refrigerator capacity (W)
- 13.400
- Refrigerator capacity (kcal / h)
- 11.524
- Nominal consumption Cold (W)
- 5.400
- Energy class (cold)
- A+
- SEER
- 5,66
- Heat capacity (W)
- 15.000
- Heat capacity (Kcal / h)
- 12.900
- Nominal heat consumption (W)
- 5.430
- Energy class (heat)
- A
- SCOP
- 3,95
- Minimum sound pressure UI DB
- 46
- Dimensions u.i (anxfxh) mm
- 600 x 350 x 1850
- Dimensions u.e (anxfxh) mm
- 950 x 370 x 965
- Weight Indoor Unit (Kg)
- 61
- Weight Outdoor Unit (Kg)
- 90
- Net weight (kg)
- 151
- Diameter Liquid pipe
- 3/8
- Diameter Gas Pipe
- 5/8
- Possibility Integration
- WiFi Included
