Air Conditioning Haier Health Connect 140 AD140S2SM9FA(H) Triphasic
Refrigeration 13400W 日本語 Heating 15000W 日本語 UVC + Wi-Fi hOn Δ Triphasic 380-415V
The Air Conditioning Haier Health Connect 140 AD140S2SM9FA(H) Triphasic represents maximum commercial power with three-phase power health Connect Series. With 13400W cooling / 15000W heating advanced health technology UVC + integrated Wi-Fi hOn, offers ultra potent air conditioning and pure air for large commercial spaces with maximum three-phase electrical stability.
13️ 13400W Refrigeration
Rank 4.0-15.0 kW
15000W Heating
Rank 4.0-16.0 kW
▪ SEER 6,1 A+++ Triphasic
380-415V/3
▼ UVC + 248mm
Health Connect
Key Specifications Health Connect 140 Triphase
Indoor Unit: AD140S2SM9FA(H)
Outdoor Unit: 1U140S2SN2FB
Air flow: 1500-2500 m3/h
Sonic Pressure: 39 dBA
Wi-Fi hOn: Smart control
Nominal consumption: 5,0 kW cold
Refrigerant Gas: R-32 (2.50 kg)
Sterilization: Integrated UVC
¿Any doubt about the product?
Talk to us and consult us. We will solve all your doubts
Ducted Air Conditioner Haier Health Connect 140 AD140S2SM9FA(H) + 1U140S2SN2FB (1 fan) Trif.
Referencia: CONDUCTOS140HCT
€2,196.42
Tax included
IMMEDIATE DELIVERY!
For deliveries in Europe, consult delivery time
Envío GRATIS en España (Península) a partir de 300€ + info
Email has been sent successfully.
Calcular Gastos de Envío
🛡️ Pago Seguro ✅ Garantía Oficial
Air Conditioning Haier Health Connect 140 AD140S2SM9FA(H) Triphasic
Refrigeration 13400W 日本語 Heating 15000W 日本語 UVC + Wi-Fi hOn Δ Triphasic 380-415V
The Air Conditioning Haier Health Connect 140 AD140S2SM9FA(H) Triphasic represents maximum commercial power with three-phase power health Connect Series. With 13400W cooling / 15000W heating advanced health technology UVC + integrated Wi-Fi hOn, offers ultra potent air conditioning and pure air for large commercial spaces with maximum three-phase electrical stability.
13️ 13400W Refrigeration
Rank 4.0-15.0 kW
15000W Heating
Rank 4.0-16.0 kW
▪ SEER 6,1 A+++ Triphasic
380-415V/3
▼ UVC + 248mm
Health Connect
Key Specifications Health Connect 140 Triphase
Indoor Unit: AD140S2SM9FA(H)
Outdoor Unit: 1U140S2SN2FB
Air flow: 1500-2500 m3/h
Sonic Pressure: 39 dBA
Wi-Fi hOn: Smart control
Nominal consumption: 5,0 kW cold
Refrigerant Gas: R-32 (2.50 kg)
Sterilization: Integrated UVC
Security policy
Delivery policy
Refund policy
Haier Health Connect 140 AD140S2SM9FA(H) + 1U140S2SN2FB
MÁXIMA POTENCIA COMERCIAL TRIFÁSICA • 13400W/15000W • UVC + Wi-Fi hOn • 248mm
: Revolutionary Health Connect 140 Triphasic: Maximum Power + Technology
The Haier Health Connect 140 AD140S2SM9FA(H) + 1U140S2SN2FB establishes a new standard in three-phase commercial air conditioning by combining maximum power of 13400W cooling / 15000W heating with advanced technology and triphase feeding 380-415V for maximum stability. This revolutionary system maintains 248mm high world record while offering superior commercial performances ideal for large spaces that require pure air and maximum power.
Designed specifically for demanding commercial and industrial applications, integrates technology Health Connect with UVC sterilization, Smart Wi-Fi and Antibacterial Filtering 99.9%, guaranteeing not only powerful air conditioning but also air completely purified for professional environments where health is a priority.
️ Maximum Commercial Power
13400W Refrigeration: Range 4.0-15,0 kW modulant
15000W Heating: Maximum range 4.0-16,0 kW
Coverage: 110-170m2 commercial spaces
・ Commercial Triphasic Food
380-415V Triphasic: Maximum trade stability
Balanced distribution: Lower current by phase
Higher efficiency: Reduction of electrical losses
▼ Advanced Health Connect Technology
🔬
UVC sterilization
LED UV light eliminates air pathogens
📱
Wi-Fi hOn Professional
Smart commercial control
️
External air
Renovation continuous clean air
️
Filtration 99.9%
Air Guard Antibacterial
En Higher Commercial Energy Efficiency
SEER 6,1 A++
Efficient cooling
SCOP 4,8 A++
Upper heating
EER 2,55
Instant performance
COP 3,30
Heat efficiency
Commercial Technical Specifications • Health Connect 140 Triphasic
DOBLE INVERTER ROTATIVE • 248mm RÉCORD • ECOLOGIC R32
Tecnología Dual Inverter Compressor Technology Commercial Rotative
The triphasic rotary inverter compressor health Connect 140 represents the maximum technological developments in commercial air conditioning. Power supply 380-415V triphase, ensures ultra-stable and efficient operation with balanced distribution of loads and minimum vibrations. The system modula from 4.0 to 15.0 kW adapting perfectly to the variable needs of large commercial spaces.
Technology Green R32 with 2.50 kg load optimizes thermodynamic performance while reducing environmental impact. His ultra-compact design 248mm high set a world record by hosting all this power in the smallest possible space, ideal for false commercial ceilings with height limitations.
️ Commercial Air Performance
Variable flow rate: 1500-2500 m3/h
Static pressure: 25-150 Pa adjustable
Sound level: 39 dBA operation
Distribution: Uniform and silent
Electrical Specifications
Food: 3 throw, 4, 380~415V, 50Hz
Consumption Cold: 5,00 kW (max.)
Consumption Calor: 4,10 kW (maximum)
Cable: 3 x 6.0 mm2 minimum
Installation dimensions and Specifications
| Component | Specification | Value |
|---|---|---|
| Indoor Unit | Dimensions (LxPxH) | 1500 x 700 x 248 mm |
| Interior weight | Neto / Brutus | 48,0 / 57,0 kg |
| Outdoor Unit | Dimensions (LxPxH) | 950 x 370 x 965 mm |
| Outer weight | Neto / Brutus | 68.0 / 73.0 kg |
| Tuberias | Liquid / Gas | 3/8" (9,52mm) / 5/8" (15,88mm) |
| Maximum length | Tuberia | 70 meters |
S Commercial applications Triphasic ideals
🏥
Health Centres
Consultations and clinics
🏢
Corporate offices
Complete plants
️
Shopping Centres
Large locations
🏭
Industrial facilities
Heated ships
Competitive Triphasic vs Monophosic Advantages
▷ Advantages Triphasic Food:
- Increased stability of electricity supply
- Balanced distribution of loads
- Lower current by phase (higher efficiency)
- Reduction of electrical losses
- More balanced operation 24/7
Es Ideal applications:
- Commercial facilities with triphase
- Intensive continuous operation
- Maximum power with stability
- Centers with high energy demand
- Professional electrical infrastructure
MOST POTENCE TRADE TRIFASICA!
Haier Health Connect 140 • 13400W/15000W • UVC + Wi-Fi hOn • 380-415V Triphasic
WORLD RÉCORD: 13400W in Solo 248mm with Triphase Feeding
The only market system that combines maximum commercial power, UVC sanitary technology and stable triphase power in ultra-compact format. Technical revolution for demanding commercial spaces!
▪
Maximum Triphasic Power
13400W/15000W with stability 380-415V
▼
UVC Health Technology
Sterilization + Wi-Fi hOn + Outdoor air
📏
248mm World Record
Ultra-compact for false ceilings
WHERE IS HEALTH CONNECT 140 TRIFÁSICO?
▷ Unique technical advantages:
- Unique maximum power with three-phase feeding
- UVC technology integrated series
- 248mm height world record
- Wi-Fi hOn advanced intelligent control
: Commercial applications:
- Health centres and medical consultations
- Corporate offices complete plants
- Commercial centres large
- Industrial facilities heated
📞 CHECK AVAILABILITY AND SPECIAL PRICE NOW!
Business air conditioning experts • Personalized technical advice • Professional installation
Commercial
info@tualmacendelclima.es
More information
Your Warehouse of Climate
⭐ OFFICIAL GARANTIA • SPECIALIZED TECHNICAL SOPORT • PROFESSIONAL INSTALMENT ⭐
CONDUCTOS140HCT
Data sheet
- Brand
- Haier
- Indoor Unit
- Outdoor Unit
- Refrigerant Gas
- R32
- Electrical supply
- Trifásica
- Refrigerator capacity (W)
- 13.400
- Refrigerator capacity (kcal / h)
- 11.524
- Nominal consumption Cold (W)
- 5.510
- Energy class (cold)
- A++
- SEER
- 6,1
- Heat capacity (W)
- 15.000
- Heat capacity (Kcal / h)
- 12.900
- Nominal heat consumption (W)
- 5.770
- Energy class (heat)
- A++
- SCOP
- 4,8
- Minimum sound pressure UI DB
- 39
- Weight Indoor Unit (Kg)
- 48,0
- Weight Outdoor Unit (Kg)
- 84,0
- Diameter Liquid pipe
- 3/8"
- Diameter Gas Pipe
- 5/8"
- Possibility Integration
- Integrated WiFi
- Recommended area
- Estancia de 110m2 aprox.
- Dimensions UI (ANXFXH) mm
- 1500 x 700 x 248
- EU dimensions (anxfxh) mm
- 950 x 370 x 965
