Ducted Air Conditioner Giatsu GIA-D-18ADM2R32-WF
Admira Plus Series 18000 BTU A++/A+ Δ Multiposition Δ Inverter DC
The Air Conditioning by Conduct Giatsu GIA-D-18ADM2R32-WF admira Plus Series sets new versatility standards with 5,28 kW in cooling and 6,01 kW in heating. Your exclusive capacity horizontal and vertical allows maximum installation flexibility, while DC inverter technology modulates from 4500 to 21000 BTU/h. With maximum static pressure of 160 Pa, A+/A+ rating (SEER 6,5 / SCOP 4,1) and eco-friendly R32 coolant, guarantees maximum energy efficiency and unprecedented versatility of installation in large spaces that demand premium air conditioning.
️ 18000 BTU Powerful
5,28 kW cold / 6,01 kW heat
Multi Multiposition
Horizontal + Vertical
Superior Higher pressure
Up to 160 Pa
Tamaño Greater Size
700×245×750 mm
Key Specifications Admira Plus Series
Capacity: 18000 BTU/h
Modulation: 4500-21000 BTU/h
Cold consumption: 1590W (360-2130W)
Consumption heat: 1615W (500-1850W)
Static pressure: 0-160 Pa
Air flow: 650-900 m3/h
Refrigerant Gas: R32 (1.15 kg)
Pipe length: Up to 30m
¿Any doubt about the product?
Talk to us and consult us. We will solve all your doubts
Ducts Giatsu GIA-D-18ADM2R32-WF Series Admires Plus Monof.
Referencia: GIA-D-18ADM2R32-WF
€881.75
Tax included
IMMEDIATE DELIVERY!
For deliveries in Europe, consult delivery time
Envío GRATIS en España (Península) a partir de 300€ + info
Email has been sent successfully.
Calcular Gastos de Envío
🛡️ Pago Seguro ✅ Garantía Oficial
Ducted Air Conditioner Giatsu GIA-D-18ADM2R32-WF
Admira Plus Series 18000 BTU A++/A+ Δ Multiposition Δ Inverter DC
The Air Conditioning by Conduct Giatsu GIA-D-18ADM2R32-WF admira Plus Series sets new versatility standards with 5,28 kW in cooling and 6,01 kW in heating. Your exclusive capacity horizontal and vertical allows maximum installation flexibility, while DC inverter technology modulates from 4500 to 21000 BTU/h. With maximum static pressure of 160 Pa, A+/A+ rating (SEER 6,5 / SCOP 4,1) and eco-friendly R32 coolant, guarantees maximum energy efficiency and unprecedented versatility of installation in large spaces that demand premium air conditioning.
️ 18000 BTU Powerful
5,28 kW cold / 6,01 kW heat
Multi Multiposition
Horizontal + Vertical
Superior Higher pressure
Up to 160 Pa
Tamaño Greater Size
700×245×750 mm
Key Specifications Admira Plus Series
Capacity: 18000 BTU/h
Modulation: 4500-21000 BTU/h
Cold consumption: 1590W (360-2130W)
Consumption heat: 1615W (500-1850W)
Static pressure: 0-160 Pa
Air flow: 650-900 m3/h
Refrigerant Gas: R32 (1.15 kg)
Pipe length: Up to 30m
Security policy
Delivery policy
Refund policy
Product Description
The Air Conditioning by Conduct Giatsu GIA-D-18ADM2R32-WF mark a milestone in the prestigious Admira Plus Series, being the first model that incorporates installation capacity horizontal and vertical, revolutionizing the possibilities of installation in architecturally challenging projects. With a robust rated capacity of 5,28 kW in cooling (18000 BTU/h) and 6,01 kW in heating (20500 BTU/h), this system employs state-of-the-art DC inverter technology that allows intelligent modulation from 4500 to 21000 BTU/h in cold mode, ensuring precise and efficient adaptation to the variable demands of the air-conditioned space.
The exceptional combination of GMCC inverter compressor and optimized DC fan ensures outstanding energy efficiency with A+ cooling rating (SEER 6,5) and A+ heating (SCOP 4,1), translated into substantial and sustained energy savings throughout the year. The system incorporates eco-friendly R32 coolant with 1,15 kg load, maximizing thermal efficiency while significantly minimizing environmental impact and long-term operating costs compared to conventional refrigerants.
La indoor Unit, with dimensions of 700×245×750 mm and weight of 24.4 kg, has been specifically designed to offer the unique versatility of installation both horizontal and vertical, providing variable airflows from 650 to 900 m3/h with adjustable upper static pressure from 0 to 160 Pa, allowing large-scale installations with extensive and complex ducts. Its optimized sound levels of 36,5/34/31 dB(A) according to speed guarantee discreet operation, ideal for spacious spaces that require professional acoustic comfort.
La outdoor Unit GMCC, with dimensions of 805×554×330 mm and weight of 32.5 kg, incorporates protection Golden Fin premium anticorrhage for maximum durability in extreme weather conditions. The system allows larger installations with a maximum pipe length of 30 meters and a height of up to 20 meters, while the cable control included offers complete weekly programming for automatic optimization of energy consumption and intelligent management of multiple climate zones.
Multiposition Revolutionary Characteristics
🔄
Multiposition installation
First Admira Plus Series unit with horizontal and vertical capacity. Maximum flexibility for complex architectural projects and reduced spaces.
📏
Higher static pressure
Up to 160 Pa for long and complex ducts. Ideal for large installations and distribution in multiple rooms.
️
Premium Power 18000 BTU
Wide 4500-21000 BTU/h cold and 5100-21500 BTU/h heat. Accurate adaptation to demanding spacious spaces.
📐
Extended installation
Pipe length up to 30m and down to 20m. Improved cold connections 1/4" - 1/2" for greater capacity.
▪
Maintained efficiency A++/A+
SEER 6,5 and SCOP 4,1 with advanced DC inverter technology. Maximum energy savings even with greater power.
🌿
R32 Ecological Optimized
1.15 kg R32 load for maximum capacity with minimal environmental impact. Sustainable cutting-edge technology.
Technical Specifications Multiposition
| Feature | Value |
|---|---|
| Model Set | GIA-D-18ADM2R32-WF (Admira Plus Multiposition Series) |
| Refrigeration capacity | 5,28 kW (1,32~6,16) - 18000 BTU/h (4500~21000) |
| Capacity Heating | 6,01 kW (1,50~6,31) - 20500 BTU/h (5100~21500) |
| Consumption Refrigeration | 1590W (360~2130W) |
| Consumption Heating | 1615W (500~1850W) |
| SEER / SCOP | 6,5 / 4,1 |
| Energy label ( Cold/Calor) | A++ / A+ |
| Installation Available | Horizontal & Vertical (Multiposition) |
| Sonic pressure Indoor Unit | 36,5/34/31 dB(A) |
| Sonic pressure Outdoor Unit | 59 dB(A) |
| Air flow rate | 900/780/650 m3/h (Alto/Medium/Bajo) |
| Static pressure | 25 Pa nominal (0-160 Pa maximum) |
| Dimensions Indoor Unit | 700×245×750 mm |
| Dimensions Outdoor Unit | 805×554×330 mm |
| Weight Indoor Unit | 24.4 kg |
| Weight Outdoor Unit | 32.5 kg |
| Refrigerant Gas / Charge | R32 / 1,15 kg |
| Length Tuberia Maximum | 30 meters |
| Maximum level | 20 meters |
| Frigorific connections | Liquid 1/4" - Gas 1/2" |
Exclusive Multiposition Benefits
✓
Revolution in Installation Flexibility
First Admira Plus series with horizontal and vertical installation. Adapts to any space: false ceilings, technical cabinets, vertical installations and special configurations.
✓
Capacity for complex installations
Static pressure up to 160 Pa and 30m of pipe allow distribution in homes/offices of multiple plants and challenging architectural configurations.
✓
Ideal power for spacious spaces
18000 BTU perfect for large rooms, large offices, commercial premises and 50-70 m2 spaces that require powerful and efficient air conditioning.
✓
Efficiency with greater power
Conserves A+/A+ classification and DC inverter technology even with 18000 BTU, ensuring substantial energy savings.
Main applications Multiposition
▪
Residencial Premium Amplio
Large living rooms, spacious homes, penthouses, duplex and residential spaces that require flexible installation and superior power.
🏢
Professional Offices and Spaces
Large offices, large meeting rooms, extensive medical consultations and professional spaces with installation limitations.
️
Trade and hospitality
Large shops, restaurants, bars, large hairdressers and shops that require installation flexibility with superior power.
Multiposition revolution for Spacious Spaces!
The Giatsu Admira Plus 18000 BTU Series breaks barriers with horizontal and vertical installation, static pressure up to 160 Pa and DC inverter technology. The final solution for projects that demand maximum flexibility without compromising efficiency.
Request your custom budget today!
GIATSU ADMIRA PLUS 18000 BTU G
Horizontal + Vertical + 160 Pa + A+/A+
Revolutionary MULTIPOSITION
Horizontal + Vertical installation
First Admir Plus multi-position series
Superior Pressure 160 Pa
Long and complex behaviours
Large-scale facilities
18️ 18000 BTU Modulante
4500-21000 BTU/h modulation
Premium power for spacious spaces
Extended installation
30m pipe + 20m
Maximum flexibility installation
▪ Ideal spaces 50-70 m2
🔄 Horizontal + Vertical Ulnic
▪ A++/A+ with 18000 BTU
🔇 Quiet since 31 dB
📐 700×245×750 mm size
🌿 Organic R32 1.15 kg
MULTIPOSITION REVOLUTION
First unit Admira Plus series with horizontal and vertical installation
Perfect for large offices, large rooms and shops
▷ SPECIALIZED MULTIPOSITION
️ Warranty 3+5 years
🔧 Technical Service Giatsu
📋 Certification A++/A+
🔄 Unique Multiposition
GIA-D-18ADM2R32-WF
Data sheet
- Brand
- Giatsu
- Indoor Unit
- Outdoor Unit
- Refrigerant Gas
- R32
- Electrical supply
- Monofásica
- Refrigerator capacity (W)
- 5.280
- Refrigerator capacity (kcal / h)
- 4.541
- Nominal consumption Cold (W)
- 1.590
- Energy class (cold)
- A++
- SEER
- 6,5
- Heat capacity (W)
- 6.010
- Heat capacity (Kcal / h)
- 5.169
- Nominal heat consumption (W)
- 1.615
- Energy class (heat)
- A+
- SCOP
- 4,1
- Minimum sound pressure UI DB
- 31
- Weight Indoor Unit (Kg)
- 24,4
- Weight Outdoor Unit (Kg)
- 32,5
- Diameter Liquid pipe
- 1/4"
- Diameter Gas Pipe
- 1/2"
- Possibility Integration
- Incluido de serie
- Recommended area
- Estancia de 45m2 aprox.
- Dimensions UI (ANXFXH) mm
- 700 x 750 x 245
- EU dimensions (anxfxh) mm
- 805 x 330 x 554
