Ducted Air Conditioner Giatsu GIAC200IX49BDT3
BIG DUCT IX49B Series ⋅ 20kW ⋅ 68200 BTU Δ DC Inverter Δ Industrial
The Giatsu GIAC200IX49BDT3 leads the BIG DUCT IX49B Series 20kW (68200 BTU) industrial power and technology compressor DC Inverter advanced. Designed for large industrial and commercial spaces up to 400 m2, it offers airflow up to 3750 m3/h, maximum energy efficiency and ultra silent operation. Its triphase configuration and compact design make it the ideal solution for industrial ships, shopping centers and professional applications that demand strong and reliable air conditioning.
・ 20kW Industrial
68200 BTU power
️ 3750 m3/h
Industrial flow
DC Inverter
Advanced compressor
hasta up to 400 m2
Industrial application
Key Specifications
Power: 20kW / 68200 BTU
Air flow: 3750 m3/h
Compressor: DC Inverter
Food: Tripha
Application: Industrial
Sound level: Ultra silent
Settings: Compacta
Installation: Professional
Reference: GIAC200IX49BDT3 Δ Giatsu BIG DUCT IX49B Industrial
¿Any doubt about the product?
Talk to us and consult us. We will solve all your doubts
Ducted Air Conditioner Giatsu GIAC200IX49BDT3 Big Duct
Referencia: GIAC200IX49BDT3
€3,538.61
Tax included
We are currently out of stock.
Ask us about availability!!
Envío GRATIS en España (Península) a partir de 300€ + info
Email has been sent successfully.
Calcular Gastos de Envío
🛡️ Pago Seguro ✅ Garantía Oficial
Ducted Air Conditioner Giatsu GIAC200IX49BDT3
BIG DUCT IX49B Series ⋅ 20kW ⋅ 68200 BTU Δ DC Inverter Δ Industrial
The Giatsu GIAC200IX49BDT3 leads the BIG DUCT IX49B Series 20kW (68200 BTU) industrial power and technology compressor DC Inverter advanced. Designed for large industrial and commercial spaces up to 400 m2, it offers airflow up to 3750 m3/h, maximum energy efficiency and ultra silent operation. Its triphase configuration and compact design make it the ideal solution for industrial ships, shopping centers and professional applications that demand strong and reliable air conditioning.
・ 20kW Industrial
68200 BTU power
️ 3750 m3/h
Industrial flow
DC Inverter
Advanced compressor
hasta up to 400 m2
Industrial application
Key Specifications
Power: 20kW / 68200 BTU
Air flow: 3750 m3/h
Compressor: DC Inverter
Food: Tripha
Application: Industrial
Sound level: Ultra silent
Settings: Compacta
Installation: Professional
Reference: GIAC200IX49BDT3 Δ Giatsu BIG DUCT IX49B Industrial
Security policy
Delivery policy
Refund policy
The Beginning of the Extreme Industrial Power
The Air Conditioning by Conduct Giatsu GIAC200IX49BDT3 marks the beginning of extreme industrial power within the BIG DUCT IX49B Series with 20kW (68200 BTU/h) capacity. Equipped with the most advanced compressor DC Inverter industrial and triphase configuration, it is designed for large commercial and industrial facilities that require robust, reliable and maximum performance air conditioning.
Its massive flow of 3750 m3/h guarantees uniform air distribution in industrial complexes of up to 400 m2, while ultra compact design and silent operation position it as the ideal solution for commercial centers, industrial ships and corporate buildings that demand the highest performance in industrial air conditioning with cutting edge technology and absolute reliability.
▪
20kW Industrial Power
68200 BTU/h industrial power for large commercial complexes and industrial installations up to 400 m2.
🔧
DC Inverter Industrial
Industrial grade DC Inverter compressor for maximum energy efficiency and continuous operation 24/7.
️
Massive range 3750 m3/h
Massive range for uniform distribution in large industrial complexes and shopping centers.
🏭
Triphase configuration
Three-phase power supply for maximum electrical stability and continuous industrial operation.
Industrial Technical Specifications
| Feature | Specification | Unit |
|---|---|---|
| Model | GIAC200IX49BDT3 | - |
| Industrial Power | 20 kW | kW |
| Frigorific power | 68200 | BTU/h |
| Compressor | DC Inverter Industrial | - |
| Electrical supply | Tripha | 380-415V |
| Massive Air Caudal | 3750 | m3/h |
| Energy efficiency | Industrial Maximum | - |
| Sound level | Ultra Quiet | dB(A) |
| Design | Ultra Compact | - |
| Operation | Continue 24/7 | - |
| Industrial Coverage | up to 400 | m2 |
| Category | INDUSTRIAL HOME | - |
Es Industrial benefits of GIAC200IX49BDT3
▪ Industrial Power
20kW for commercial centers, industrial ships and large-scale complexes
DC Inverter Industrial
Maximum efficiency and continuous operation 24/7 without interruptions
Tri Triphasic Stability
Three-phase power supply for maximum industrial electrical stability
️ Caudal Masivo
3750 m3/h for uniform distribution in mega installations
Why choose to choose Giatsu GIAC200IX49BDT3 Industrial?
: Industrial applications Home:
- Medium shopping centres and large shops
- Industrial ships and production workshops
- Corporate buildings and office complexes
- Logistics centres and warehouses
- Hospitals and health centres
- Facilities that require up to 400 m2 of coverage
▼ Advantages Industrial Power:
- Industrial power 20kW (68200 BTU) for large spaces
- DC Inverter Industrial Grade Compressor
- Massive range 3750 m3/h for mega-installations
- Three-phase power supply for electrical stability
- 24/7 continuous operation without interruption
- Ultra compact design for complex installations
Request your Budget for the Giatsu GIAC200IX49BDT3!
20kW Industrial - The Beginning of Extreme Power for Large Complexes
What WhatsApp
Industrial consultancy
▪ 20kW
68200 BTU
Tripha
Industrial stability
GIAC200IX49BDT3
Data sheet
- Brand
- Giatsu
- Indoor Unit
- Outdoor Unit
- Refrigerant Gas
- R410A
- Electrical supply
- Trifásica
- Refrigerator capacity (W)
- 20.000
- Refrigerator capacity (kcal / h)
- 17.200
- Nominal consumption Cold (W)
- 5.920
- SEER
- 6,5
- Heat capacity (W)
- 22.000
- Heat capacity (Kcal / h)
- 18.920
- Nominal heat consumption (W)
- 5.350
- SCOP
- 4,3
- Minimum sound pressure UI DB
- 45
- Weight Indoor Unit (Kg)
- 102,0
- Weight Outdoor Unit (Kg)
- 112,7
- Diameter Liquid pipe
- 1/2"
- Diameter Gas Pipe
- 7/8"
- Possibility Integration
- It does not incorporate WiFi
- Recommended area
- Consultation
- Dimensions UI (ANXFXH) mm
- 1440 x 811 x 448
- EU dimensions (anxfxh) mm
- 1015 x 450 x 1430
