Air Conditioning Cassette Giatsu GIAC9T3-60ADM2R32WF
Refrigeration 15240W 日本語 Heating 18170W 日本語 SEER 6,1 A++ 日本語 Panel 90x90
The Air Conditioning Cassette Giatsu GIAC9T3-60ADM2R32WF represents mega maximum absolute triphase power of the Cassette Admira Plus Series 15240W in cooling and 18170W in heating. Power supply 380-415V triphase, panel 90x90 standard and technology DC Inverter complete, offers maximum 4-way air conditioning with remote control included for commercial and industrial mega-installations that require maximum power and absolute stability.
️ 15240W Refrigeration
Rank 4,10-16,12 kW
18170W Heating
Rank 4,40-19,05 kW
▪ SEER 6,1 A++
SCOP 4.0 A+
3 380-415V Triphasic
Mega maximum stability
Key Specifications Cassette Admira Plus T3-60
Indoor Unit: GIA-C9I-60ADM2R32WF
Outdoor Unit: GIA-UOT3-60ADM2R32
Air flow: 1650-2000 m3/h
Sonic Pressure: 40-53 dBA
Food: 380-415V Triphase
Nominal consumption: 5,70 kW cold
Refrigerant Gas: R-32 (3.2 kg)
Protection: Golden Fin
¿Any doubt about the product?
Talk to us and consult us. We will solve all your doubts
Cassette 90x90 Giatsu GIA-C9T3-60ADM2R32WF trif.
Referencia: GIA-C9T3-60ADM2R32WF
€2,259.09
Tax included
IMMEDIATE DELIVERY!
For deliveries in Europe, consult delivery time
Envío GRATIS en España (Península) a partir de 300€ + info
Email has been sent successfully.
Calcular Gastos de Envío
🛡️ Pago Seguro ✅ Garantía Oficial
Air Conditioning Cassette Giatsu GIAC9T3-60ADM2R32WF
Refrigeration 15240W 日本語 Heating 18170W 日本語 SEER 6,1 A++ 日本語 Panel 90x90
The Air Conditioning Cassette Giatsu GIAC9T3-60ADM2R32WF represents mega maximum absolute triphase power of the Cassette Admira Plus Series 15240W in cooling and 18170W in heating. Power supply 380-415V triphase, panel 90x90 standard and technology DC Inverter complete, offers maximum 4-way air conditioning with remote control included for commercial and industrial mega-installations that require maximum power and absolute stability.
️ 15240W Refrigeration
Rank 4,10-16,12 kW
18170W Heating
Rank 4,40-19,05 kW
▪ SEER 6,1 A++
SCOP 4.0 A+
3 380-415V Triphasic
Mega maximum stability
Key Specifications Cassette Admira Plus T3-60
Indoor Unit: GIA-C9I-60ADM2R32WF
Outdoor Unit: GIA-UOT3-60ADM2R32
Air flow: 1650-2000 m3/h
Sonic Pressure: 40-53 dBA
Food: 380-415V Triphase
Nominal consumption: 5,70 kW cold
Refrigerant Gas: R-32 (3.2 kg)
Protection: Golden Fin
Security policy
Delivery policy
Refund policy
1 Triphase and DC Inverter Mega Maximum
The Cassette Air Conditioner Giatsu GIAC9T3-60ADM2R32WF integration 380-415V for mega maximum absolute operational stability, combined with technology DC Inverter complete both in compressor and fan. With SEER 6,1 A++ in cooling and SCOP 4.0 A+ in heating, its power 15240W cold and 18170W in heat position it as the maximum absolute power solution for commercial and industrial mega-installations that require maximum stability and absolute mega-efficiency.
The triphasic system modifies its power from 4100W to 16120W in cold and from 4400W up to 19050W in heat, distributing the electrical loads in a balanced way and ensuring stable maximum mega-function with minimal fluctuations in any ultra demanding operating condition.
2 Panel 90x90 Standard and Distribution Mega Maximum Industrial
Equipped with standard panel 90x90 cm without independent control of lamas, the GIAC9T3-60ADM2R32WF provides uniform air distribution through its 4 directional lanes. The variable flow rate 1650 to 2000 m³/h guarantees optimal coverage for spaces 140 to 180 m2, maintaining homogeneous temperature in demanding commercial and industrial mega-instalations.
La indoor Unit of 830x287x830 mm is integrated into false standard industrial ceilings, while their operation 40 to 53 dBA maintains acoustic comfort suitable for workers in commercial and industrial environments of mega maximum three-phase power.
3 Intelligent Control and Mega Industrial Features
The equipment includes remote serial control with 24-hour programming functions, allowing advanced time and temperature configuration to optimize energy consumption in intensive and continuous industrial applications. La protection Golden Fin in exchangers protects against marine corrosion and aggressive mega industrial environments, while the integrated capacitor pump facilitates automatic evacuation of condensed water without additional installations.
4 Refrigerant Gas R32 Ecological and Operational Efficiency Mega
Use coolant Organic R32 with load of 3.2 kg, reducing environmental impact and improving energy efficiency.The three-phase system operates over an extended range of -15°C to +50°C in refrigeration and -20°C to +24°C in heating, ensuring reliable year-round operation in mega-industrial facilities with mega-demanding climatic conditions.
La outdoor Unit three-phase 975x980x375 mm facilitates installation in mega-large industrial spaces, with refrigeration connections 3/8" liquid and 5/8" gas and maximum pipe length of 75 meters with a slope of up to 30 meters, providing maximum flexibility in large mega-project industrial complex mega scales.
Complete Technical Specifications
| Feature | Specification | Feature | Specification |
|---|---|---|---|
| Refrigeration | 15240W (4100-16120W) | Heating | 18170W (4400-19050W) |
| SEER / SCOP | 6.1 A++ / 4.0 A+ | Nominal consumption | 5700W / 5550W |
| Food | 380-415V Triphase | Air flow | 1650-2000 m3/h |
| Sound level | 40-53 dBA | Refrigerant Gas | R32 (3.2 kg) |
| Max Pipe | 75m / 30m deseven | Weight Neto UI | 29.3 kg + 6 kg panel |
Commercial and Industrial Applications Mega Recommended
S Corporate Megaoffices
Spaces 140-180m2 large mega corporate that require mega maximum power with stable mega-phase power.
Es Industrial Superinstallations
Large mega industrial ships and superinstallations that need maximum mega air conditioning with mega-balanced triphase power.
S️ Gastronomic Super Complexes
Supercomplete gastronomics and megafood courts that require maximum mega-hydropower air conditioning.
S Supercentros Médicos
Large mega-hospitals and medical supercentres that need stable maximum mega-host air conditioning with absolute 24/7 continuous operation.
Extended warranty Giatsu
3 years guarantee total + 5 years warranty compressor
GIA-C9T3-60ADM2R32WF
Data sheet
- Brand
- Giatsu
- Indoor Unit
- GIA-C9I-60ADM2R32WF
- Outdoor Unit
- GIA-UOT3-60ADM2R32
- Panel
- GIA-C9P-ADM2R32
- I send
- Mando Infrarrojos
- Color
- Blanco
- Refrigerant Gas
- R32
- Electrical supply
- Trifásica
- Recommended area (M2)
- Estancia de 120 a 135 m2
- Refrigerator capacity (W)
- 16.000
- Refrigerator capacity (kcal / h)
- 13.760
- Nominal consumption Cold (W)
- 5.700
- Energy class (cold)
- A++
- SEER
- 6,1
- Heat capacity (W)
- 18.170
- Heat capacity (Kcal / h)
- 15.626
- Nominal heat consumption (W)
- 5.550
- Energy class (heat)
- A+
- SCOP
- 4,0
- Minimum sound pressure UI DB
- 40
- Dimensions u.i (anxfxh) mm
- 830 x 830 x 287
- Dimensions u.e (anxfxh) mm
- 975 x 375 x 980
- Weight Indoor Unit (Kg)
- 29,3
- Weight Outdoor Unit (Kg)
- 92,0
- Net weight (kg)
- 123,8
- Diameter Liquid pipe
- 3/8
- Diameter Gas Pipe
- 5/8
- Possibility Integration
- WiFi Included
